Wilhelm Maybach (9 February 1846 – 29 December 1929) was an early German engine designer and industrialist. During the 1890s he was hailed in France, then the world centre for car production, as the "King of constructors".
From the late 19th century Wilhelm Maybach, together with Gottlieb Daimler, developed light, high-speed internal combustion engines suitable for land, water, and air use. These were fitted to the world's first motorcycle, motorboat, and after Daimler's death, to a new automobile introduced in late 1902, the Mercedes model, built to the specifications of Emil Jellinek.
Maybach rose to become technical director of the Daimler Motoren Gesellschaft, or DMG, (and never known by the English name of the quite separate English business, The Daimler Motor Company) but he did not get on well with its chairmen. As a result Maybach left DMG in 1907 to found Maybach-Motorenbau GmbH together with his son Karl in 1909; they manufactured Zeppelin engines. After the signing of the Versailles Treaty in 1919 the company started producing large luxury vehicles, branded as "Maybach". The company joined the German war effort in 1940, ceasing automotive production in favour of tank engines, including those for Tiger tanks.
In 1998 Daimler-Benz merged with Chrysler Corporation to become DaimlerChrysler. The new company revived the Maybach brand name as a luxury make in 2002. On November 25, 2011, Daimler-Benz announced they would cease producing automobiles under the Maybach brand name in 2013.
Early life and career beginnings (1846 to 1869)
Wilhelm Maybach was born in Heilbronn, Baden-Württemberg in 1846, the son of a carpenter and his wife Luise. He had four brothers. When he was eight years old the family moved from Löwenstein near Heilbronn to Stuttgart. His mother died in 1856 and his father in 1859.
After his relatives published an announcement in the Stuttgarter Anzeiger newspaper, a philanthropic institution at Reutlingen took in Maybach as a student. Its founder and director, Gustav Werner, discovered Maybach's technical inclination and helped to stimulate his career by sending him to the school's engineering workshop. At 15 years old (1861), Maybach was heading for a career in Industrial design and took extra classes in physics and mathematics at Reutlingen's public high school.
By the time he was 19 years old, he was a qualified designer working on stationary engines. His workshop manager, Gottlieb Daimler, then 29, noticed his efforts and took him on as his main assistant, a post he held until Daimler's death in 1900.
Daimler and Otto's four-stroke engine (1869 to 1880)
In 1869, Maybach followed Daimler to Maschinenbau-Gesellschaft Karlsruhe AG in Karlsruhe, a manufacturer of heavy locomotives. Daimler was on the Executive Committee and they spent long nights discussing new designs for engines, pumps, lumber machinery, and metalworking.
In 1872, Daimler moved to Deutz-AG-Gasmotorenfabrik in Cologne, then the world's largest manufacturer of stationary gas engines. Nikolaus Otto, part owner of the company, focused on engine development with Daimler. Maybach joined them as Chief Designer.
In 1876, Nikolaus Otto patented the Otto cycle engine. It was a four-stroke cycle gas internal combustion engine with intake, compression, power, and exhaust strokes. Otto's patent on this engine was later challenged and overturned.
Also in 1876, Maybach was sent to show Deutz's engines at the Philadelphia World's Fair (USA). On returning to Cologne in 1877, he concentrated on improving the four-stroke design to get it ready for its impending commercial launch.
In 1878, Maybach married Bertha Wilhelmine Habermaas a friend of Daimler's wife, Emma Kunz. Her family members were landowners who ran the post office in Maulbronn. On 6 July 1879 Karl Maybach was born, the first of their three sons.
In 1880, Daimler and Otto had serious disagreements which resulted in Daimler leaving Deutz-AG. Daimler received 112,000 goldmarks in Deutz-AG shares as compensation for patents granted to him and Maybach. Maybach also left shortly afterwards, and followed his friend to found a new company in Cannstatt.
Daimler Motors: fast and small engines (1882)
In 1882, Maybach moved to Taubenheimstrasse in Cannstatt, Stuttgart where Daimler had purchased a house with 75,000 goldmarks from his Deutz compensation. They added a brick extension to the glass-fronted summer house in the garden, which became their workshop.
Their activities alarmed the neighbours who suspected they were engaged in counterfeiting. The police raided the property in their absence using the gardener's key, but found only engines.
In 1884, Maybach's second son, Adolf was born.
The Grandfather Clock engine (1885)
By the end of 1885, Maybach and Daimler developed the first of their engines, which is regarded as a precursor to all modern petrol engines. It featured:
single horizontal cylinder
large cast-iron flywheel
revolutionary hot tube ignition (Patent 28022)
exhaust valve controlled by a camshaft allowing high speeds
a speed of 600 rpm, when at the time most engines could only achieve about 120 to 180 rpm.
In 1885, they created the first carburetor, which mixed evaporated gasoline with air to allow its efficient use as fuel. It was used that year on a larger but still compact version of the engine, now with a vertical cylinder, that featured:
1 Horsepower at 600 rpm output
100 cc engine displacement
non cooled insulated cylinder with unregulated hot-tube ignition (patent DRP-28-022)
Daimler baptized it the Standuhr (Grandfather Clock) because of its resemblance to a pendulum clock.
In November 1885, Daimler installed a smaller version of the engine into a wooden bicycle, creating the first motorcycle (patent 36-423 - Vehicle with gas or petroleum engine), and Maybach drove it three kilometers from Cannstatt to Untertürkheim, reaching 7.5 mph (12 km/h). It became known as the Reitwagen.
On 8 March 1886, the inventors took a stagecoach built by Wilhelm Wimpff & Sohn inside the house, telling the neighbours that it was a birthday gift for Mrs. Daimler. Maybach supervised the installation of an enlarged 1.5 hp Grandfather Clock engine into the coach, and installed a belt drive to the wheels. The vehicle reached 10 mph (15 km/h) when tested on the road to Untertürkheim.
Maybach and Daimler went on to prove the engine in many other ways, including:
On water (1887). It was mounted in a 4.5-metre-long boat which achieved 6 knots (11 km/h). The boat was called the Neckar after the river it was tested on and was registered as patent number DRP 39-367. Motor boat engines would become their main product until the first decade of the 1900s.
More road vehicles, including street cars
In the air. They built the first motorized airship, a balloon based on designs by Dr. Friedrich Hermann Wölfert from Leipzig. They replaced his hand operated drive system and flew over Seelberg successfully on 10 August 1888.
By 1887 they were licensing their first patents abroad, and Maybach represented the company at the great Paris Exposition Universelle (1889).
First Daimler-Maybach automobile built (1889)
Steel Wheel Automobile 1889
· high speed four-stroke petrol engine
· fuel vaporization
· 2 cylinders V-configured
· mushroom shaped valves
· 4-speed toothed gearbox
· pioneer axle-pivot steering system
Sales increased, mostly from the Neckar motorboat. In June 1887, Daimler bought land in the Seelberg Hills of Cannstatt. The workshop was some distance from the town on Ludwig Route 67, because Cannstatt's mayor objected to the presence of the workshop in the town. It covered 2,903 square meters and cost 30,200 goldmarks. They initially employed 23 people. Daimler managed the commercial issues and Maybach the design department.
In 1889 they built their first automobile to be designed from scratch rather than as an adaptation of a stagecoach. It was publicly launched by both inventors in Paris in October 1889.
Daimler's engine licenses began to be taken up throughout the world, starting the modern car industry in:
France, 1890, Panhard & Levassor and Peugeot
United Kingdom, 1896, The Daimler Motor Company of Coventry
United States of America, 1891, Steinway
Austro-Daimler in Austria, starting in 1899
Daimler's "pact with the devil", DMG, and the Phoenix engine (1890 to 1900)
Resources were scant to keep the business going as neither the engine sales nor the worldwide proceeds from their patents were yielding enough money. Fresh capital was injected by bringing in the financiers Max von Duttenhofer and William Lorenz, former munitions makers, who were associated with Kilian von Steiner, the owner of a German investment bank. The company was taken public.
In 1890, Daimler and Maybach together founded the Daimler Motoren Gesellschaft, the Daimler Motor Corporation or DMG for short, which was dedicated to the construction of small high speed internal combustion engines for land, water, or air transport. Maybach was Chief Designer. After spending long hours debating which fuel was best to use in Otto's four-stroke engine, which had normally used methane gas as a fuel, they turned to petroleum which until then had been used mainly as a cleaner and sold in pharmacies.
The company's re-foundation took place on 28 November 1890. This has been regarded as a "pact with the devil" by some German historians, as the following decade was chaotic for Daimler and Maybach. DMG continued to expand, selling engines from Moscow to New York, and additional stationary engine-making capacity was added, but the belief continued that automobile production wouldn't be profitable. The new chairmen planned to merge DMG and Deutz-AG, in spite of Gottlieb's disagreement with Nikolaus Otto.
Daimler and Chief Engineer Maybach preferred to produce automobiles and reacted against Duttenhofer and Lorenz in particular. Maybach was rejected as a member of the Board of Management and left the company on 11 February 1891, and continued his design work from his own house, financed by Gottlieb Daimler. In late 1892, he set up a shop in the ballroom of the former Hermann Hotel and Winter Garden where he employed 17 workers, five of which were paid by Daimler.
In 1894 Maybach designed his third engine model, together with Daimler and his son Paul. Used in the Phoenix, it gained worldwide attention, pioneering the use of four cylinders in the automobile and featuring:
single block casting of cylinders, arranged vertically and parallel to each other
camshaft controlled exhaust valves
spray-nozzle carburetor (patented by Maybach in 1893)
improved belt drive
Maybach's creations are considered some of the finest motors of the second half of the 19th century. His inventions became indispensable for any model by any automaker in the world. He became recognised as the backbone of France's early automobile industry, where he was hailed as the "King of Constructors".
Daimler was forced out of his post as Technical Director at DMG and resigned in 1893, which damaged DMG's prestige. However, in 1894, a British industrialist, Frederick Simms, purchased the rights to the Phoenix engine for 350,000 marks and stabilised the companies finances. He also made it a condition that Daimler was re-employed. In 1895 DMG assembled its 1,000th engine, and Maybach also returned as Chief Engineer, obtaining 30,000 Goldmark worth of shares through his original contract with Gottlieb Daimler.
Maybach patented more automobile inventions, including:
a revolutionary cooling system, tubular radiator with fan the honeycomb radiator
Around this time though Maybach suffered two setbacks. His teenage second son, Adolf, suffered a schizophrenia attack and spent the rest of his life in various mental institutions (In 1940 he was murdered by the Nazis as part of the Euthanasia Program). In 1900, Gottlieb Daimler died of heart disease.
Daimler-Mercedes engine of 1900
Mercedes 35 hp (1902)
· Large wheelbase. Wide track
· Pressed steel framework. Lightweight metals
· Low center of gravity (lower engine)
· 75 km/h (45 mph). 35 hp (950 rpm)
· 300 to 1000 rpm (driver controlled)
· Light and high-performance engine: 4 in-line cylinders
· Bore/stroke ratio: 116x140 mm
· Displacement: 5918 cc
· Cylinder heads part of the castings
· Two carburetors, one for each cylinder pair
· Driver controlled intake valve throttling
· Two camshafts
· 4-forward/1-reverse transmission
· Low voltage ignition magnetos
· Aluminium crankcase (pioneer), horizontally divided
· Honeycomb radiator
· Comfortable ride
Between April and October 1900, Maybach designed a completely new kind of car inspired by racing which would be called the Mercedes 35 hp when released in 1902. It featured:
unheard-of power from its 35 hp engine allowing it to reach 40 mph (64,4 km/h).
Emil Jellinek, a successful Austrian dealer and racing driver on the French Riviera who greatly admired Maybach's work, promised to buy a shipment of 36 automobiles for 550,000 goldmarks if Maybach could design a great race car for him following his specifications.
The prototype was finished in December 1900 and, in 1901 went on to have a string of racing successes. Its engine was baptized Daimler-Mercedes (Spanish for mercy) after Mercedes Jellinek, Emil's 10–year–old daughter. European high society bought the car in large numbers making it the commercial success that convinced the company directors there was a future in automobiles. Production increased greatly and DMG rapidly increased in size and number of employees. DMG officially registered the Mercedes trademark in June 1902.
In 1902, a fire destroyed DMG's Cannstatt facilities and the company moved to Stuttgart-Untertürkheim. Maybach continued with his innovations:
a 6-cylinder/70 hp engine (1903–04)
a pioneer aircraft engine: a high speed racing engine of 120 hp, with overhead inlet and exhaust valves and double ignition (1906)
DMG demoted him to an "Inventor's Office" causing him to leave the company again in 1907. DMG replaced him with Paul Daimler. That same year, the German Engineers Association (VDI) recognized Wilhelm Maybach as an honorary member.
Zeppelin engines (1908)
In 1900, Maybach had had his first contact with Count Ferdinand von Zeppelin who sought to improve the engines of the Zeppelin LZ1 airship. Maybach built some engines for him based on sketches of a 150 hp unit created by his son, Karl, while at DMG.
In 1908, Count Zeppelin attempted to sell his models LZ3 and LZ4 to the government. On 5 August, LZ4 exploded against a row of trees after attempting an emergency landing when its engines failed. This was far from being the end for the airship project as 6.25 million goldmarks were raised in a donation campaign after the accident. Count Zeppelin founded the Luftschiffbau Zeppelin GmbH, the company that built the Zeppelin airships.
Maybach had to hold off joining the new company for a while as he was still in litigation with DMG so Karl took his place. On 23 March 1909, a deal was finally signed, creating an engine subsidiary to Luftschiffbau Zeppelin at Bissingen/Enz, in Württemberg. Wilhelm Maybach was Technical Assistant and Karl was Technical Manager. Their first designs reached 72 km/h (45 mph).
Wilhelm Maybach moved his company to Friedrichshafen and renamed it Luftfahrzeug-Motoren-GmbH. Karl and Wilhem held 20% of the shares with an arrangement for Karl to inherit. They kept supplying Zeppelin, but worked on other airship engines too. In 1912, the company adopted the name Maybach-Motorenbau GmbH (Maybach Engine Construction Company). In 1916, they developed a 160 hp aircraft engine which sold 2000 units before the end of World War I. In 1916, Wilhelm Maybach was awarded an Honorary Doctorate by the Technical University of Stuttgart.
Maybach automobiles (1922)
After the First World War, the Versailles Treaty of 1919 prohibited airship production in Germany so Maybach turned to making high-speed diesel engines for naval and railroad use, and petrol engines for automobiles, but not complete automobiles.
Many of the small automakers in Germany built their own engines for cost reasons and only the Dutch Spyker company was interested in taking Maybach engines. Wilhelm Maybach turned down the contract because he could not agree to its conditions. Instead, he opted to build complete automobiles and the factory began to produce Maybach limousines in 1921.
The first model, the Maybach W3, was shown at the 1921 Automobile Exposition in Berlin and featured
new transmission system
maximum speed of 105 km/h (65 mph)
It was produced until 1928, selling 300 units, mostly with sedan bodies; the two-seat sport version was less successful. The Maybach W5 followed, with the top speed increased to 135 km/h (84 mph); 250 units sold in 1927 and 1929.
Next Maybach produced the V12 car:
the first 12-cylinder German automobile
lightweight aluminium engine based on his airship work
light alloy pistons
high torque and power - 150 hp (110 kW) at 2,800 rpm
Only a few dozen were sold due to the German postwar economic crisis. In 1930, its successor, the DS7-Zeppelin, also featured a 12-cylinder engine of 7 liters.
In August 1929, the Zeppelin LZ-127 used five Maybach-V12 petrol engines of 550 hp (410 kW) each.
Neither Wilhelm nor Karl owned a Maybach automobile. Wilhelm never even owned a car. "He, who created the basics for the modern automobilism, rarely utilized a car for his personal purposes. He walked or took the tram. Although he could have afforded one, he did not own a car."
Final years of DMG (1924–1929)
By 1924 DMG was suffering from the post war economic crisis and under pressure from the banks, it began the process that would result in a merger with Karl Benz's Benz & Cie., Rheinische Gasmotorenfabrik Mannheim in 1926 to form Daimler-Benz AG.
Wilhelm Maybach died at the age of 83 in Stuttgart on 29 December 1929.
Wilhelm Maybach was accepted into the Automotive Hall of Fame in 1996.
Three technical Schools in Germany are named Wilhelm Maybach: Stuttgart, Heilbronn, and Berlin-Spandau.
In 2002, Daimler AG began to produce models under the Maybach name.
In 2005, in honor of his grandfather Karl and his great-grandfather Wilhelm, Ulrich Schmid-Maybach founded the Wilhelm and Karl Maybach Foundation.
